Fiscal printers
FP20 Online PRO fiscal printer

FP20 Online PRO fiscal printer

for download

product sheet

EPSON TM-T20 gen.3 printing mechanism

Can be operated in a vertical and horizontal position

Displays: integrated and free-standing LCD and external built-in OLED

Freestanding or integrated graphic display available

FP20 Online PRO fiscal printer

Delivers speed, reliability, and complete customisation

Instant paper roll change

Modern design

Possibility of working in a vertical position (option of installation in SCO cash registers)

Possibility to create personalised non-fiscal printouts, with any content (including graphics)

Increased print speed over version 1.

The printer is compatible with previous models offered by Exorigo-Upos

Define and use eight customizable graphics at the same time

Graphics can be added and removed smoothly

350,000 items of a dynamically created product database

Our device supports the implementation of sustainable development assumptions:

EPSON’s printing mechanism is very fond of Blue4’s phenolic-free paper.

Ecology without compromise – high print quality on environmentally friendly paper

It does not get dirty or show technical degradation from printing on such paper.

Ecology and efficiency

Technical specifications

Key data

Dimensions [W/H/D] in mm Mechanism itself: W 140 D 200 H 145 Integrated
Alphanumeric: W 165 D 226 H 245 or 415
Integrated Graphic: W 175 D 230 H 280 or 450

Weight (without paper) in kg 2.5 kg (integrated display, paperless)

Colour Black

Can be operated vertically or horizontally Yes

Operating temperature [°C] (range from – to) 5°C – +45 °C

Operating humidity [%] 10% – 60% (non-condensing)

Power 230V Mains – battery, external power supply +24V DC, 1.5 A

Power Consumption Maximum: 48 W
Type: 33 W
Standby: 5 W

Power Cable Length (Total) 300 cm (including power supply, can be corrected with mains cable)

Protected memory 32GB

CPU Specifications Processor 792 MHz,
RAM 512 MB,
EMEMC memory 16GB

System Linux

Print engine

Print Type Thermal

Producer EPSON TM-T20

Paper Parameters width 79.5 +/- 0.5 mm,
maximum roll diameter 83 mm (length depends on the granulation and diameter of the core).
The mechanism allows the use of ecological papers

Mechanism Noise (dB) 55 dB

Print speed (lines/sec) 47 l/s

Maximum number of characters per line 64

Print engine life [in million lines] 15 million

Printhead life (km) 150 km

Paper cutter without cutting, complete cut, partial cut, controlled by POS software during a single print or automatic

Maximum number of paper cutter cut-offs 1,5 million

Simple paper change (easy loading) yes

Customer display

Display Type Built-in / Freestanding / Mountable in self-checkout devices

Display type Graphic / Alphanumeric / OLED (only for installation in SCO devices)

Backlight color Alphanumeric honey OLED white

Number of lines for alphanumeric displays 2

Number of lines for a graphic display 4 Transaction Lines + Summary

Number of characters per line Alphanumeric 20 characters
OLED 20 characters
Graphic 800×480 7″, 28 characters

Connectors

Communication with the cash register system RS232, USB-B, ETH

Communication with the systems of the Ministry of Finance ETH

Controlling the money drawer yes

Other connectors USB-A

Keyboard

Keyboard Type Mechanical

Number of keys 2

Drawer for money and documents

Power Max 24V/1A

Control by a fiscal printer yes

Fiscal printer software

Number of daily reports 2100

Multicurrency yes

Buyer’s NIP on the receipt yes

Fiscal invoice yes

Graphic Logo yes

Text footer yes

Text Footer – quantity up to 35

Graphic footer yes

Printing capability 1D or 2D barcode yes

Number of programmable graphics to print 8 (512×511 pixel graphics), they can be replaced during operation.

Number of products 350 thousand

Number of PTU rates 7

Number of cashiers unlimited

Memory recall on the mandatory periodic inspection yes

eParagon – possibility of sending to the client’s server yes

eParagon – operation MF HUB yes

eParagon – shipping via the sales system/central yes, the possibility of transmitting data to one of the two servers

Device Network Configuration (Static) Possibility to enter a fixed IP address, Masks, gateways, DNS

Possibility to configure a time server yes (GUM server recommended)

Download

Type approval for the FP20 Online PRO fiscal printer
